Product Specification
- Brand : Antminer APW3 -12-1600
- Rated Power 1600w(200V – 240V); 1200w(100V – 140V);
- Interface Type 6PIN x 10
- Package Size 332mm x 170mm x 125mm
- Working Voltage 110V – 220V.
- Accessory Needed NO power cable (The power cable should be easily attainable locally.)
Specifications
|
DC Voltage |
12.15V |
|
|
Rated Current |
133A |
|
|
Rated Current |
100A |
|
|
Rated Power |
1600W |
|
|
Rated Power |
1200W |
|
|
Ripple & Noise |
<1% |
|
|
Voltage Regulation |
<2% |
|
|
Source Regulation |
<1% |
|
|
Load Regulation |
<1% |
|
|
Setup, Rise Time |
<2S |
|
|
Power off Protection Trip Time |
>9mS |
|
| Interface Type | 5 pairs of 6 pin PCI-E connectors (i.e. 10 connectors) | |
|
Noise Level |
<43DB |
|
|
|
Voltage Range |
100-240V AC |
|
Starting Voltage |
95-105V AC |
|
|
Frequency Range |
47-63Hz |
|
|
Power Factor |
>0.95 (full load) |
|
|
Leakage Current |
<1.5mA (220V 50Hz) |
|
|
|
Low-voltage Input |
80-89V AC |
|
Output Short Circuit |
Yes |
|
|
Output Overcurrent |
134-185A max. |
|
|
Overheat Protection |
Yes |
|
|
|
Operating Temperature |
-20°C – 50°C |
|
Operating Humidity |
20% – 90% relative humidity (non-condensing) |
|
|
|
Dimensions |
220mm*108mm*62mm |
|
|
Fan |
Forced-air cooling |
